基本误差:≦ 8﹪(带定位器)、≦25﹪(不带定位器)
回差:≦2.5﹪(带定位器)≦2.5﹪(不带定位器)
线性:≦1.0﹪(带定位器)≦6﹪(不带定位器)
系数误差:≦±10﹪(KV≦5时±15﹪)
泄 漏 量:≦0.01﹪阀额定容量
可调范围:30:1
阀体
型式:直通单座铸造球形阀
公称通径:3/4、20、25、32、40、50、65、80、100、150mm
公称压力:ANSI125、150;PN1.6、4.0MPa
连接形式:法兰式:标准按ANSI B16.5、JB/T79.1-79.2-94
材料:ZG230-450衬F46
工作温度:-50-+150℃
压盖形式:螺栓压紧式
填料:V型聚四氟乙炔填料
阀内组件
阀芯特性:单座柱塞阀芯
阀芯材料:ZGr13衬F46
阀座材料:衬F46
波纹管材料:聚四氟乙炔
执行机构
型式:ZHA弹簧砵满盘执行机构
膜片材料:乙丙橡胶夹尼龙、丁腈橡胶夹尼龙布
弹簧范围:0.02-0.10、0.08-0.24MPa
供气压力:0.14-0.40MPa
气源接头:Rc1/4
环境温度:-30-+70℃
作用形式:气开式、气关式
备注:该阀可以配用VA5或VA6和VP执行机构
联系上海上仪仪表厂,我们期待与您合作!
